20V Brushless Rotary Hammer Kit (Model : 8910K)

Features

• 4-in-1 Multifunctional Operation

  Features 4 operational modes: Drilling (wood/metal), Hammer Drilling (concrete/brick), Chiseling (tile/mortar removal), and Chisel Angle Adjusting (releasing/rotating the chisel to the desired angle).

• High-Efficiency Waterproof Brushless Motor

  Delivers maximum power efficiency, longer motor life, and superior moisture resistance, achieving up to 1,400 RPM no-load speed and 4,500 IPM impact rate.

• Die-Cast Aluminum Gear Housing

  Built with lightweight yet exceptionally strong die-cast aluminum housing for high structural rigidity and superior heat dissipation during prolonged drilling.

• SDS Plus Tool-Free Automatic Chuck

  Allows quick, tool-free bit changes with an automatic locking mechanism, ensuring secure bit retention under intense vibration.

• High-Torque Safety Clutch Protection

  Integrated mechanical safety clutch automatically disengages the drive if the drill bit binds or jams, protecting the operator’s hands/wrists and safeguarding the motor armature.

• Ergonomic 360° Auxiliary Handle & Lock-On Switch

  Includes a 360-degree rotating anti-vibration auxiliary handle with a depth gauge for exact hole depths, paired with a lock-on switch button for continuous fatigue-free drilling.

Specification

Recommended Applications

• Concrete & Masonry Construction: Drilling anchor holes in concrete, brickwork, stone, and solid block up to 22mm diameter.

• Chiseling & Demolition: Light demolition, tile removal, trenching, and surface scaling in renovation or electrical installation projects.

• Wood & Steel Drilling: High-speed drilling in steel (up to 13mm) and wood (up to 28mm) using standard hex/straight shank adapters.

• Electrical & Plumbing Installation: Mounting conduits, pipe brackets, junction boxes, and HVAC ductwork on job sites without power grid access.

OEM Service

We provide full OEM/ODM power tool manufacturing services customized for global importers, trade brands, and wholesale distributors:

• Brand Logo Application: Laser marking, silk screening, or molded logo badges on the tool body, battery casing, and BMC hard case.

• Custom Housing Colors: Custom plastic body injection molding matching your brand’s Pantone color palette.

• Tailored Packaging & Manuals: Personalized color sleeves, custom blow mold case design, and multi-language user instruction manuals.

• Battery & Charger Options: Options for battery pack capacities (2.0Ah, 4.0Ah, 5.0Ah) and custom power charger plug standards (EU, US, UK, AU).

• International Compliance: Certified under CE, GS, RoHS, and EMC standards for seamless market clearance worldwide.

FAQ

Q1: What accessories are included in the standard 8910K kit?

A: The standard 8910K kit includes: 1× 20V Cordless Brushless Rotary Hammer, 2× 20V 4.0Ah Lithium-ion Batteries, 1× Fast Charger, 1× 360° Side Handle, 1× Depth Gauge, and 1× Heavy-Duty BMC Carrying Case.

Q2: What is the maximum drilling diameter in concrete?

A: The maximum recommended drilling capacity in concrete is 22mm (13mm in steel, 28mm in wood).

Q3: Does this tool feature a chiseling function?

A: Yes, it has 4 selectable functions: Drilling, Hammer Drilling, Chiseling, and Chisel Angle Rotation adjustment for precise positioning during chipping work.

Q4: What shank type does the chuck accept?

A: It utilizes a standard SDS Plus tool-free automatic chuck system compatible with all standard SDS Plus bits.

Q5: What is the minimum order quantity (MOQ) for OEM customization?

A: MOQ depends on your customization scope (e.g., logo printing, custom body colors, or localized box artwork). Contact our trade sales team for detailed OEM quotations.
